PE Foam hose Extrusion line: Production of Polyethylene foam tube/hose, backup materials and shock-protective materials, which can be applied to heat insulating materials field, such as heat-insulation of air-conditioning, cold & warm water pipe

· Application: - Heat Insulating materials for
agriculture and architecture; - Shock-absorbing packaging materials; - Foam Hose for Heat Insulation; - Backup Materials; - Shock-protective materials

Model	HSTC-PE65	HSTC-PE68	HSTC-PE70	HSTC-PE80
L/D	50:1	50:1	50:1	50:1
Sheet Width (mm)	6 - 35	8 - 38	12 - 43	16 - 61
Sheet Thickness (mm)	11 - 50	18 - 50	22 - 60	32 - 81
Capacity (kg/hr)	20 - 25	25 - 30	30 - 35	40 - 50
Screw Dia(㎜)	65	68	70	80
Blowing Agent	Butane Gas
