Forming machine Ⅰ, Ⅱ

Forming machine Ⅰ: Conception for production of pair type & single type heat insulating barrel for piping air-conditioning

Model	HS-TP-FM21
Inside Diameter(㎜)	8 - 35
Thickness(㎜)	5 - 10
Forming Capacity	OD. 18㎜ - 55㎜
Line Speed (m/hr.)	360 - 2100
Electrical Supply Power	3P × 380/440v × 50/60㎐
Size(㎜)	W.600 × L.2000 × H.900

Forming machine Ⅱ: Conception for production of heat insulating barrel for architectural piping

Model	HS-TS-FM21	HS-TS-FM22
Inside Diameter(㎜)	8 - 35	10 - 150
Thickness(㎜)	5 - 30	5 - 40
Forming Capacity	OD. 18㎜ - 95㎜	OD. 20㎜ - 230㎜
Line Speed (m/hr.)	180 - 2100	500 - 1500
Electrical Supply Power	3P × 380/440v × 50/60㎐
Size(㎜)	W.700 × L.1500 × H.800
